| Category: | Cylinder Filter |
| Material: | Stainless Steel wire mesh |
| Properties: | Stainless Steel Filter |
| Application: | Filtration,fuel Filter,Hydraulic Filter |
Material: Stainless Steel Wire
Wire Diameter:0.025-1.80mm
Mesh counts:1mesh to 635mesh
Weave:plain weave, twilled weave, plain dutch weave, dutch twill weave.
Packaging: water-proof outside and plastic inside
Properties: resistant acid and alkalis, high temperature resistant, pull and wear resistance
Uses:used to sieving and filter in acid and alkali conditions, oil industry as mud mesh, chemical fiber industry as screen mesh, plating industry as pickling mesh.
Packing: inside plastic film, outside water proof paper or woven bag, or as the customers’ requirement.
Stainless Steel Square Wire Mesh Sizes:
Standard roll width of stainless steel square wire mesh: 1m to 8m
Standard roll length of stainless steel square wire mesh: 30m to 200m
We also can produce according to the customers' requirements.
We produce stainless steel wire mesh from first class stainless steel wire material in SUS/AISI 201 202 302 304 310 310S 316 316L 321 430 etc.
If you can envision it,We can supply it. TEL:0086-0311- 83289301 E-mail:sales@ubooem.com
· Ubo will do everything possible to provide exact and full product information based on metal mesh for your information.
· In order to give customer a clear image of the product,Ubo has taken some pictures, customer can dowmload for reference but using our picture for business is forbidden.
· Due to technique and other factors,product image might be slight different to the products itself,in case everything will follow the products.
· Ubo appreciate any suggestion on our product information or picture or anything else.
|
Specification List of Stainless Steel Wire Mesh |
|||||||
|
Mesh/Inch |
Wire Diameter(mm) |
Aperture (mm) |
Filtration Area% |
Mesh/Inch |
Wire Diameter(mm) |
Aperture |
Filtration Area% |
|
5 |
1.00 |
4.08 |
64 |
100 |
0.11 |
0.144 |
32 |
|
6 |
0.90 |
3.33 |
62 |
120 |
0.09 |
0.122 |
33 |
|
8 |
0.70 |
2.47 |
61 |
150 |
0.065 |
0.104 |
38 |
|
10 |
0.50 |
2.04 |
64 |
200 |
0.05 |
0.077 |
37 |
|
12 |
0.50 |
1.62 |
59 |
200 |
0.04 |
0.084 |
47 |
|
14 |
0.50 |
0.50 |
52 |
250 |
0.04 |
0.062 |
37 |
|
16 |
0.35 |
1.24 |
61 |
250 |
0.035 |
0.067 |
43 |
|
18 |
0.28 |
1.13 |
64 |
250 |
0.03 |
0.072 |
50 |
|
20 |
0.35 |
0.92 |
52 |
300 |
0.04 |
0.045 |
28 |
|
24 |
0.35 |
0.71 |
45 |
300 |
0.03 |
0.055 |
42 |
|
28 |
0.35 |
0.56 |
38 |
325 |
0.035 |
0.043 |
30 |
Specification:
Looped Looped Wire screens provide the perfect solution to vibratory applications that require high strength both laterally and transversely.
Wires are looped around a supporting cross rod and compressed to fit snugly.
Slots can be manufactured to 0.005”.
Looped Wire is used in the following industries; Brewing, Pulp and Paper, Chemical, Mining and Aggregate and Waste Water, and more.
Supplied in both straight and deep arch design.
Deep arch design provides several advantages to a straight wire, especially in a dewatering sieve application:
Concentrates the liquid at the low point of the arch and away from the support bars.
Reduces blinding (clogging).
Self-cleaning due to the side way movement of the liquid.
Higher retention rates.
Increased flow capacity.
Our Services:
1. Professtional
Export more than 70 countries and real professional manufacture.
2.Product Quality
The quality of products is the key of enterprise survival. Our Wire Mesh is ISO9001:2008 certificated manufacturer.
3. Reasonable Price
We’ll exact control each producing process to reduce cost for our customers. After clients receive the quotation, we’ll show you the rationality of the price and the difference between our products and other supplier’s products.
4. Delivery Time
The customer’s needs is delivering on time, rather than an excuse. We’ll make a production plan before producing, and the sales will regularly inform the production schedule and process to the customer.
5. Communication
English is the basic and other languages can be understand. All customer’s e-mail will be replied within 2 hours at working hours and must be replied within 12 hours at non-working hours.
6. Customized
Personalized, professional service: we can provide different programs according to customers’ requirement, thus make customers choose the best and most approprite one.
Uses:used to sieving and filter in acid and alkali conditions, oil industry as mud mesh, chemical fiber industry as screen mesh, plating industry as pickling mesh.
Packing: inside plastic film, outside water proof paper or woven bag, or as the customers’ requirement
